Ti6al4V Gr1 Gr2 ASTM B265 Gr1 Gr2 Gr3 Gr5 Gr7 Hot DIP Galvanized/Black Mild/ERW /Carbon Welded/Square/Alloy/Titanium Stainless Steel Pipe

Siamo una fabbrica specializzata nella produzione di tubi in acciaio inossidabile, titanio e lega, compresi tubi saldati, quadrati e zincati a caldo. Contattaci oggi per un preventivo!
Richiede una citazione

Dettagli prodotti

  • Panoramica
  • FAQ
Panoramica

Informazioni di Base.

Model No.
Ti6al4V Gr1 Gr2 ASTM B265 Gr1 Gr2 Gr3 Gr5 Gr7
spessore
0.4 mm
lunghezza
3 mm-2500 mm
grado 1
Gr1 ,Gr2,G,Gr7,Gr9,Gr12
Pacchetto di Trasporto
Standard Export Package.
Specifiche
as customers′requirement.
Marchio
Yitejia
Origine
Tianjin China
Codice SA
81089040
Capacità di Produzione
100 Tons/Month

Descrizione del Prodotto

COMPANY PROFILE

1.SGS and BV Audited company.
2.Industry experience over 20 years.
3.Management Systems-Internal Software
4.Finished Product Inventory-More Than 5000 Tons.
5.Raw Material inventory -Over 800 Mertic Tons.
6.Shipment of goods -More than 50 countries worldwide.
7.We have the most convenient transport and prompt delivery.
8.We offer competitive price with best service.
9.We have high technical production line with top quality products.
10.We have win high reputation based on best quality products.



Titanium Alloy Bar Price Alloy pipe Ti6al4V Gr1 Gr2 ASTM B265 Gr1 Gr2 Gr3 Gr5 Gr7

PRODUCTS INFORMATIONS

Company Tianjin Yitejia Steel Sales Co.,Ltd.
Description Titanium plate, Titanium sheet, Titanium coil
Material Gr1, Gr2, Gr3,Gr4,Gr5, Gr7, Gr6,Gr9, Gr11, Gr12 ,Gr16, Gr17,Gr25
TA0,TA1,TA2,TA5,TA6,TA7,TA9,TA10,TB2,TC1,TC2,TC3,TC4
Standard ASTM B265,ASME SB265,DIN17851,TiA16Zr5Mo1.5,JIS4100-2007,GB3461-2007
Size Cold rolled: Thick 0.02mm ~ 5mm * Wide 1500mm max * Long 2500mm max

Hot rolled: Thick 5mm ~ 100mm * Wide 3000mm max * Long 6000mm max
Price term Ex-Work,FOB,CNF,CFR,CIF,FCA,DDP,DDU,etc
Payment term  TT,L/C
MOQ 100Kg
Export to Ireland,Singapore,Indonesia,Ukraine,Saudi Arabia,Spain,Canada,USA,Brazil,Thailand,Korea,
Iran,India,Egypt,Oman,Dubai,Kuwait,Peru,South Africa,Russia,Malaysia,Chile,etc
Package Standard export package,suit for all kinds of transport ,or as required.
Container
Size
20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)
Application 1.Based on High intensity,titanium products tensile strength can be up to 180Kg/mm².
2.Titanium and titanium alloy in aviation industry, is called "space metal"; In addition,
 in the shipbuilding industry, chemical industry, manufacturing machinery parts,
telecommunications equipment, hard alloy, etc have increasingly extensive application
3.In addition, because of the titanium alloy with the human body has very good compatibility,
 so the titanium alloy can also be artificial bone.
Contact If you have any question ,please feel free to contact me .
We are sure your inquiry or requirements will get prompt attention.

Chemical Composition

Grade N C H Fe O Al V Pa Mo Ni Ti
Gr1 0.03 0.08 0.015 0.2 0.18 / / / / / Bal
Gr2 0.03 0.08 0.015 0.3 0.25 / / / / / Bal
Gr3 0.05 0.08 0.015 0.3 0.35 / / / / / Bal
Gr4 0.05 0.08 0.015 0.5 0.4 / / / / /
Gr5 0.05 0.08 0.015 0.4 0.2 5.5-6.75 3.5-4.5 / / / Bal
Gr7 0.03 0.08 0.015 0.3 0.25 / / 0.12-0.25 / / Bal
Gr9 0.03 0.08 0.015 0.25 0.15 2.5-3.5 2.0-3.0 / / / Bal
Gr12 0.03 0.08 0.015 0.3 0.25 / / / 02-0.4 0.6-0.9 Bal

Mechanical properties Requirements

Grade Tensile strengt(min) Yield strength(min) Elongaion(%)
Ksi MPa Ksi Mpa
Gr1 35 240 20 138 24
Gr2 50 345 40 275 20
Gr3 65 450 55 380 18
Gr4 80 550 70 483 15
Gr5 130 895 120 828 10
Gr7 50 345 40 275 20
Gr9 90 620 70 438 15
Gr12 70 438 50 345 18

OUR PRODUCTS
Ti6al4V Gr1 Gr2 ASTM B265 Gr1 Gr2 Gr3 Gr5 Gr7 Hot DIP Galvanized/Black Mild/ERW /Carbon Welded/Square/Alloy/Titanium Stainless Steel Pipe

Ti6al4V Gr1 Gr2 ASTM B265 Gr1 Gr2 Gr3 Gr5 Gr7 Hot DIP Galvanized/Black Mild/ERW /Carbon Welded/Square/Alloy/Titanium Stainless Steel Pipe

Ti6al4V Gr1 Gr2 ASTM B265 Gr1 Gr2 Gr3 Gr5 Gr7 Hot DIP Galvanized/Black Mild/ERW /Carbon Welded/Square/Alloy/Titanium Stainless Steel Pipe

OUR TEAMS AND CERTIFICATED

Ti6al4V Gr1 Gr2 ASTM B265 Gr1 Gr2 Gr3 Gr5 Gr7 Hot DIP Galvanized/Black Mild/ERW /Carbon Welded/Square/Alloy/Titanium Stainless Steel Pipe
Ti6al4V Gr1 Gr2 ASTM B265 Gr1 Gr2 Gr3 Gr5 Gr7 Hot DIP Galvanized/Black Mild/ERW /Carbon Welded/Square/Alloy/Titanium Stainless Steel Pipe


FAQ



Ti6al4V Gr1 Gr2 ASTM B265 Gr1 Gr2 Gr3 Gr5 Gr7 Hot DIP Galvanized/Black Mild/ERW /Carbon Welded/Square/Alloy/Titanium Stainless Steel Pipe



Contattaci

Non esitare a inviare la tua richiesta nel modulo sottostante Ti risponderemo entro 24 ore
